How to protect the motor

As a widely used power equipment in industrial production, the normal operation of motor is very important to ensure production efficiency and equipment safety. However, due to the complex working environment and frequent load changes, various faults may occur in the operation of the motor, such as overload, short circuit, phase loss, undervoltage and high temperature. Therefore, it is particularly important to protect the motor scientifically and effectively.

First of all, the overload protection of the motor is an important measure to prevent the motor from being damaged due to long-term overload operation. Usually, thermal relay or electronic overload relay is used to realize it. When the motor current exceeds the rated value for a certain period of time, the protection device will automatically cut off the power supply, thus protecting the motor from overheating.

Secondly, short-circuit protection is a quick response mechanism for short-circuit faults of motor windings or lines. Short-circuit current is extremely large, which can easily cause serious damage to equipment and even fire. Therefore, fuses or circuit breakers are usually used to realize short circuit protection, and the power supply is quickly cut off at the moment of short circuit.
　　hirdly, the open-phase protection has been paid more and more attention in recent years. If one phase of a three-phase motor is cut off in operation, the torque of the motor will decrease and the current will increase, which will cause the motor to overheat or even burn out. To this end, you can install a phase-loss protector or use equipment such as frequency converters with phase-loss protection function.

In addition, undervoltage and overvoltage protection can not be ignored. If the voltage is too low, the motor current will increase and the speed will decrease, which will affect the normal operation. However, if the voltage is too high, it may break through the winding insulation and cause short circuit. By using voltage relay or intelligent controller, the power supply can be cut off in time when the voltage is abnormal.
　　The temperature protection of the motor is a protective measure directly aimed at the temperature of the motor body. A temperature sensor (such as PTC thermistor) is embedded in the motor. When the temperature exceeds the set value, the control system will automatically stop the motor to prevent the insulation from aging and burning.

Finally, regular maintenance is also an indispensable part of motor protection. Including checking the lubrication of motor bearings, whether fasteners are loose, winding insulation, etc., to ensure that the motor is always in good working condition.

To sum up, the safe operation of the motor is inseparable from perfect protection measures. Through reasonable electrical protection and routine maintenance, the service life of the motor can be effectively extended, the reliability of equipment operation can be improved, and the continuity and safety of production can be guaranteed. Therefore, in practical application, a comprehensive motor protection system should be constructed by comprehensively selecting a variety of protection methods according to the type, working environment and control requirements of the motor.
