Accuracy of rotary direct drive servo valve

As a key component in hydraulic control system, servo valve is widely used in industrial automation, aerospace, robotics and other fields. Its core function is to convert electrical signals into hydraulic signals, so as to accurately control the movement of the actuator. In recent years, with the increasing demand for control accuracy, Rotary Direct Drive Servo Valve (RDDSV) has attracted wide attention because of its advantages of fast response, compact structure and low energy consumption. Among them, accuracy, as one of the core indexes to measure the performance of servo valve, directly determines the control quality and operation stability of the system.

First, the working principle of rotary direct drive servo valve

Different from the traditional nozzle flapper servo valve, the rotary direct-drive servo valve directly drives the spool to rotate by torque motor, which saves the intermediate amplification link and realizes the simplification of structure and the improvement of response speed. By controlling the magnitude and direction of current, the position of the valve core can be accurately adjusted, thus achieving high-precision control of flow and pressure.
　　econd, the main factors affecting the accuracy

1. Manufacturing and assembly error: Precise manufacturing technology and assembly accuracy are the premise to ensure high performance of servo valve. Any slight deviation will cause spool deviation, which will affect the linearity of output and the accuracy of repeated positioning.

2. Material and thermal expansion: The difference of expansion of different materials under the change of working temperature may cause the gap between the valve core and the valve body to change, and then affect the control accuracy.

3. Nonlinear characteristics of drive system: The torque motor itself has nonlinear factors such as hysteresis and saturation, which may cause spool position control error.

4. Control algorithm and feedback mechanism: Using high-precision encoder and advanced control algorithm (such as PID, fuzzy control and adaptive control) can significantly improve the overall accuracy of servo valve.

Third, technical means to improve accuracy

1. Closed-loop control technology: It is an effective method to improve the accuracy by introducing a high-resolution position sensor and a closed-loop feedback system to correct the displacement error of the spool in real time.

2. Digital control and intelligent algorithm: With the help of digital signal processor (DSP) and field programmable gate array (FPGA), accurate modeling and compensation control of servo valve dynamic characteristics can be realized.

3. Optimize the structural design: optimize the shape of the valve core and the structure of the driving system by finite element analysis (FEA), reduce the influence of friction and inertia, and improve the dynamic response and positioning accuracy.

4. New materials and precision machining technology: the use of materials with high wear resistance and low expansion coefficient, combined with micro-scale or even nano-scale machining technology, can significantly improve the stability and repeatability of servo valves.

IV. Application Prospects and Challenges

Rotary direct drive servo valve has shown great potential in robot joint control, aircraft control system, CNC machine tools and other fields. However, in the face of multiple requirements such as high precision, high frequency response and high reliability, it is still necessary to make continuous breakthroughs in material science, control theory and manufacturing technology.

tag
　　With the development of intelligent manufacturing and high-end equipment, the accuracy of rotary direct-drive servo valve has become one of the key bottlenecks restricting its wide application. Through the integration of system optimization design, advanced control strategy and precision manufacturing technology, it is expected to significantly improve the accuracy of servo valves and provide strong support for the development of high-end hydraulic control technology in China.
